ABSTRACT
Wood-based panels are a group of products with a wide range of applications, which are not obtained from solid wood, but are made from its fragments, such as wood chips, sawdust or wood dust, which are usually waste from production. The recycled material, after being mixed with a binder, is compressed. As a consequence of such a process, different types of boards are obtained: MDF (Medium-Density Fiberboard), HDF (High-Density Fiberboard), fiberboard or particleboard. In response to the problems accompanying the use of MDF and HDF boards, a new type of CDF (Compact Density Fibreboard) wood-based boards has been developed. In the paper the strength properties of CDF panels reinforced with melamine films were investigated for four thicknesses: 6.4 mm, 8.4 mm, 10.4 mm and 12.4 mm. Young's modulus E, tensile strength Rm and percentage total extension at fracture At were determined from the static tensile test. The obtained results of the strength tests of wood-based panels were subjected to statistical analysis to determine the effect of the thickness of the panel on its strength. CDF boards are characterized by low total elongation at break of about 0.5% and show higher stiffness due to higher Young's modulus (at least 5,600 MPa). Statistical analysis has shown that for boards up to 12.4 mm thick, their thickness usually does not affect the strength properties. The only exception is the Young's modulus values for the thickness of 12.4 mm.
REFERENCES (21)
1.
Arendarski J. (2013): Measurement uncertainty (in Polish). Warsaw: Publishing House of the Warsaw University of Technology.

2.
Borysiuk P., Furmanik A., Auriga R., (2019): Impact of conditions of use on selected properties of furniture particleboards finished with melamine film. Biuletyn Informacyjny Ośrodka Badawczo-Rozwojowego Przemysłu Płyt Drewnopochodnych w Czarnej Wodzie. No. 3/4. pp. 107-117.

3.
Franco M., Silva M.F., Prates G., Gali L., Savi A., Favarim H., Caraschi J., Campos C. (2024): Physical-mechanical properties of MDF panels with the addition of melaminę paper in the internal layer, Cadero Pedagogico. Vol. 21, No. 1, pp. 2992-3001.

4.
Hunt J. F., Vick C.B. (1999): Strength and processing properties of wet-formed hardboards from recycled corrugated containers and commercial hardboard fibers. Forest Products Journal. 49(5), pp. 69-74.

5.
Jakimovska Popovska V., Iliev B., Spiroski I. (2016): Characteristics of Medium Density Fiberboards for Furniture Production and Interior Application. South East European Journal of Architecture and Design, p. 10013.

6.
Kim M.H., Song H.B. (2014): Analysys of the global warming potential for wood waste recycling systems. Journal of Cleaner Production, 69, pp. 199-207.

7.
Kostyrko K., Piotrowski J. (2012): Calibration of measuring equipment (in Polish). Warsaw: PWN Scientific Publishing House.

8.
Lieber E., Pawlak D., Boruszewski P. (2018): Analiza wpływu okresu sezonowania płyt wiórowych na ich właściwości mechaniczne. Biuletyn Informacyjny Ośrodka badawczo-Rozwojowego Przemysłu Płyt Drewnopochodnych w Czarnej Wodzie. No. 1/2, pp. 118-128.

9.
Lubis M.A.R., Hong M.K., Park. B.D., Lee S.M. (2018):. Effects of recycled fiber content on the properties of medium density fiberboard. European Journal Wood and Wood Products. 76(6). pp. 1515-1526.

10.
Md. Rowson A., Ummi Hani A., Zaidon A., Lee S.H., Norul Hisham H., Siti Hasnah K., (2022): Physical properties of hydrothermally treated rubberwood [Hevea brasiliensis (Willd. ex A. Juss.) Mull. Arg.] in Different Buffered Media. Forests, Vol. 13, No. 7, pp. 1-14.

11.
Nourbakhsh A., Ashori A., Jahan-Latibari A. (2010): Evaluation of the physical and mechanical properties of medium density fiberboard made from old newsprint fibers. Journal of Reinforced Plastics and Composites. 29(1), pp. 5-11.

12.
Oniśko W. (2011): New generations of wood-based composites and modern technologies. In Proceeding of the Drewnowizja, Instytut Technologii Drewna w Poznaniu.

13.
Rabiej M. (2018): Statistical analysis with the programs Statistica and Excel (in Polish). Gliwice: Helion Publishing House.

14.
Roila A., Noorshamsiana A. W., Zawawi I., Astimar A.A. (2023): Medium density fibreboard (MDF) from oil palm fibre: a review, Malaysian Journal of Analytical Sciences, Vol. 27, No. 3, pp. 626- 640.

15.
Sala C. M., Robles E., Kowaluk G. (2020): Influence of adding offcuts and trims with a recycling approach on the properties of high-density fibrous composites. Polymers. Vol. 12(6).

16.
StatSoft (2006): Elektroniczny Podręcznik Statystyki PL. Retrieved from https://www.statsoft.pl/textbo....

17.
Swiss Krono (2023). Catalog: SwissCDF innovatively furnishes interiors (in Polish). Swiss Krono.

18.
Swiss Krono: Product card – MDF, LDF, HDF boards.

19.
Sydor M., Wołpiuk M. (2016): Analysis of Resistance to Axial Withdrawal of Screws Embedded in Locally Reinforced MDF. Drewno, pp. Vol. 59, No. 196, pp. 173-182.

20.
Youngquist J. A. (1999): Wood-based Composites and Panel Products. In F. P. Laboratory, Wood handbook: wood as an engineering material. General technical report FPL; GTR-113. Madison, WI: U.S. Department of Agriculture, Forest Service, Forest Products Laboratory.

21.
Zhao J., Tian D., Shen F., Hu J., Zeng Y., Huang C. (2019): Valorizing waste lignocellulose-based furniture boards by phosphoric acid and hydrogen peroxide (Php) pretreatment for bioethanol production and high-value lignin recovery. Sustainability, 11, 6175.
